SERIES 116 - THERMOSTATIC REGULATOR FOR HOT WATER RECIRCULATION C/W THERMAL DISINFECTION FUNCTION

The Altecnic thermostatic regulator for domestic hot water re-circulation systems automatically maintain the specified water temperature.
The thermostatic regulator is intended to be installed in the return pipe of each re-circulation circuit, automatically maintaining the specified water temperature. The regulator controls the flow rate in accordance with the inlet water
temperature by means of a dedicated internal thermostatic cartridge. When the water temperature approaches the set value, the obturator progressively closes and reduces the flow passage reducing the amount of water re-circulating.
The water supplied by the re-circulation pump is available to be distributed to other branches in the system, resulting in effective automatic thermal balancing. The regulator is equipped with a thermal disinfection function, which is useful if the water temperature exceeds 55 to 60˚C



● Kv maximum: 1.8 m3/h, Kv minimum: 0.2 m3/h
● Max working pressure: 10 bar
● Max differential pressure: 1 bar
● Temperature adjustment range: 35 - 60°C (½” - ¾”)
● Temperature adjustment range: 35 - 65°C (1” - 1¼˝)

View Product Codes and Technical Documents
Grouped product items
Reference Name Size Product Description Accreditations
116140 116 Series - Thermal Balancing Valve ½˝ Regulator with probe pocket for temperature gauge
116150 116 Series - Thermal Balancing Valve ¾″ Regulator with probe pocket for temperature gauge
116240 116 Series - Thermal Balancing Valve ½″ Regulator with temperature gauge
116250 116 Series - Thermal Balancing Valve ¾″ Regulator with temperature gauge
116160 116 Series - Thermal Balancing Valve For actuator-controlled thermal disinfection function
116170 116 Series - Thermal Balancing Valve 1¼˝ For actuator-controlled thermal disinfection function
116260 116 Series - Thermal Balancing Valve 1" For actuator-controlled thermal disinfection function with gauge
116270 116 Series - Thermal Balancing Valve 1¼˝ For actuator-controlled thermal disinfection function with gauge
