280 ANTI-CONDENSATION VALVE WITH THERMOSTATIC CONTROL OF THE RETURN TEMPERATURE TO SOLID FUEL GENERATORS

The Altecnic anti-condensation valve connects between a biomass burning boiler and a direct or indirect heating system or domestic hot water system. It automatically controls the return temperature to the boiler to avoid
condensation, by means of an integral thermostatic sensor. Keeping the boiler at a high temperature prevents condensation forming from the water vapour contained in the flue gases. It can be used on central biomass boilers or residential biomass burners such as fireplace heating systems and solid fuel stoves and cookers. The anti-condensation valve gives the boiler a longer life and ensures greater efficiency.

Design

Multi-functional Body
The compact brass single body casting houses the thermostatic sensor and temperature gauge pockets enables immediate installation of the unit, either on the right or left of the biomass boiler, respecting the flow directions as shown. The brass body prevents the formation of ferrous residues in the system, thereby helping to prolong the life of the boiler.

Anti-condensation valve
Anti-condensation valve incorporates a thermostatic sensor to control the temperature of water returning to the boiler, preventing the formation of condensation. The sensor has been specifically designed to be removed from the
valve body for maintenance, re-setting or replacement if necessary.

Pockets for Temperature Gauges
The body of the anti-condensation valve in sizes DN25 (1”) and DN32 (1¼”) have pockets for temperature gauges on the front and rear sides. The pockets allow the installation of suitable temperatures gauges for measuring the three water temperatures and re-setting the thermostat if required.
